Exhaust Back Pressure Regulator Piston - Sensed Leakage Rate 2*10-8 Atm Cc / Sec He

Product Categories

Shenzhen Wofly Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Place of Origin : Guangdong, China (Mainland)

Brand Name : AFK

Model Number : RW72

Supply Ability : 10000 Set/Sets per Week

Packaging Details : Export packing

MOQ : >=1 Sets

Price : Negotiable

Certification : CE

Structure : Piston-sensed Configuraton

Maximum inlet pressure : 6000 psig

Proof pressure : 1.5 times of maximum rated presure

Working temperature : -40° F ~+165° F(-40°C+74°C)

Leakage rate : 2*10-8 atm cc/sec He

Cv : 0.15

Body material : 316L

Seat : Vespel

Port : SHENZHEN

Contact Now

Product Description

Technical parameters

Maximum Inlet Pressure	6000psi
Proof pressure	1.5times maximum inlet pressure
Safety test pressure	1.5 times maximum inlet pressure
Operating Temperature	-40°F to 165°F / -40°c to 74°c
Leakage Rate Against Atmosphere	2*10-8atm cc/sec he
Cv value	0.15

Material of Parts

Ordering Information

Exhaust Back Pressure Regulator Piston - Sensed Leakage Rate 2*10-8 Atm Cc / Sec He

Product Tags:

back pressure control valve
